MTR3CMOS技术参数

MTR3CMOS20000KPA
MTRP120000A(New)

20M/IMX183(C)
1 “(13.056x8.755)

2.4 x2.4

462mv with 1/30s
0.21mv with 1/30s

5@5440x3648

10@4096x2160

15@2736x1824

30@1824x1216

1x1,

1x1,
2x2,

3x3

0.1ms~3600s

MTR3CMOS20000KMA
MTRM120000A(New)

20M/IMX183(M)
1 “(13.056x8.755)

2.4 x2.4

388mv with 1/30s
0.21mv with 1/30s

(F8.0)

17.8@5440x3648

41@4096x2160

51@2736x1824

64@1824x1216

1x1,

1x1,
2x2,

3x3

0.1ms~3600s

MTR3CMOS16000KPA
MTRP116000A（New）

16M/MN34230PLJ(C)
4/3“ (17.6x13.3)

3.8x3.8

2413LSB
89.1LSB
(Gain = 0dB)

6@4640x3506
20@2304x1750
48.0@1536x1160

1x1
2x2
3x3

0.15ms~3600s

MTR3CMOS16000KMA
MTRM116000A（New）

16M/MN34230ALJ(M)
4/3“ (17.6x13.3)

3.8x3.8

2650LSB
89.1LSB
(Gain = 0dB)

22.5@4648x3506
43.0@2304x1750
48.0@1536x1168

1x1
2x2
3x3

0.15ms~3600s

MTR3CMOS10300KPA
MTRP110300A（New）

10.3M/IMX294(C)
4/3 “(17.47x12.86)

4.63 x4.63

419mv with 1/30s
0.12mv with 1/30s

7.5@3704x2778
10 @4096x2160
60 @2048x1080
96@1360x720

1x1,
1x1,
2x2,
3x3

0.15ms~3600s

MTR3CMOS07100KPA
MTRP107100A(New)

7.0M/IMX428(C，GS)
1.1 “(14.4x9.9)

4.5 x4.5

2058mv with 1/30s
0.15mv with 1/30s

12@3200x2200

33@1600x1100

1x1

1x1

0.1ms~3600s

MTR3CMOS07100KMA
MTRM107100A(New)

7.0M/IMX428(M，GS)
1.1 “(14.4x9.9)

4.5 x4.5

3354mv with 1/30s
0.15mv with 1/30s

51@3200x2200

133@1600x1100

1x1

2x2

0.1ms~3600s

MTR3CMOS01700KPA
MTRP101700A(New)

1.7M/IMX432(C，GS)
1.1 “(14.4x9.9)

9.0 x9.0

4910mv with 1/30s
0.3mv with 1/30s

33@1600x1100

1x1

0.1ms~3600s

MTR3CMOS01700KMA
MTRM101700A(New)

1.7M/IMX432(M，GS)
1.1 “(14.4x9.9)

9.0 x9.0

8100mv with 1/30s
0.3mv with 1/30s

94@1600x1100

1x1

0.1ms~3600s

光谱响应范围

380-650nm (有红外截止滤光片情况下)

白平衡

ROI 白平衡/手动Temp-Tint调整/黑白相机不提供

色彩还原技术

Ultra-Fine TM颜色处理引擎

捕获/控制API

Native C/C++,C#, DirectShow, Twain和Labview

记录方式

图像和视频(软件或硬件触发)

制冷方式*

双级循环式热电制冷系统，低于环境温度42度以下，精准可控)(视传感器型号略有差别)

工作温度（摄氏度）

-10~ 50

贮存温度（摄氏度）

-20~ 60

工作湿度

30~80%RH

贮存湿度

10~60%RH

供电电源

相机通过USB3.0接口供电(兼容USB2.0)

制冷模块通过外部电源供电，DC12V，3A

操作系统

Microsoft® Windows®XP/ Vista / 7 / 8 /10(32 & 64 位)

OS X (Mac OS X)

Linux

计算机配置

CPU:Intel Core 2 2.8GHz 或更高

内存:2GB或更大

USB接口:USB3.0高速接口，兼容USB2.0接口

显示器:17”或以上

CD-ROM
